AMaViS - A Mail Virus Scanner

Christian Bricart, shiva@aachalon.de
Rainer Link, link@suse.de

version 0.2.1, $Date: 2000/10/31 10:59:53 $

This document describes version 0.2.1 of AMaViS - A Mail Virus Scanner for Linux and other UN*X based platforms ( tested to run on Solaris, *BSD, AIX, HP-UX, too )

IMPORTANT NOTE: A lot of features have been added to amavis-perl and amavisd, which are not described in this document! Please read the README files within the amavis-perl/amavisd package! The development of the AMaViS 0.2.x tree has been discontinued

1. Introduction

2. System Requirements

2.1 Virus Scanners

2.1.1 Network Associates Virus Scan

2.1.2 DrSolomon (obsolete)

2.1.3 H+BEDV AntiVir/X

2.1.4 Sophos Sweep

2.1.5 Kaspersky Lab AntiViral Toolkit Pro (AVP)

2.1.6 CyberSoft VFind

2.1.7 Trend Micro FileScanner

2.1.8 CAI InoculateIT

2.1.9 F-Secure Inc. (former DataFellows) F-Secure AV

2.2 Mail Transport Agents

2.2.1 Sendmail

2.2.2 QMail

2.2.3 Postfix

2.2.4 Exim

2.3 MIME Handlers

2.3.1 metamail

2.3.2 reformime

2.4 Decompressors and Decoders

2.4.1 uudecode

2.4.2. compress

2.4.3 gunzip

2.4.4 unzip

2.4.5 unarj

2.4.6 unrar

2.4.7 xbin

2.4.8 LHArc

2.4.8 bunzip2

2.4.9 zoo

2.4.10 arc

2.4.11 freeze

2.4.12 tnef

2.5 File Type Recognition

2.5.1 file

3. Installation Instructions

3.1 Installing the Software

3.2 Modifying /etc/sendmail.cf

3.2.1 Modifying /etc/sendmail.cf manually

3.2.2 Modifying sendmail.cf via M4 macros

3.3 Testing Installation

4. Download

5. Future Outlook

6. Known Bugs

7. Disclaimer

8. Copyright

9. Credits

10. AMaViS in the press

11. History and Changes

1. Introduction

Most people will say: "A virus scanner? For UN*X? Why? Viruses do not work in a UNIX environment." On the first glance they are right (even if there are at least two viruses which run under Linux - well, actually they are Trojan Horses)

On the second view though, imagine a heterogene network environment with both UN*X and DOS / Windows / Macintosh workstations. Now think of an UN*X server that serves Windows and/or Macintosh workstations via a POP3 service. Would it not be nice to ensure attachments coming via email are scanned for viruses before they reach a system they are able to infect? Well - that is what this package is for. It resides on the server that handles your incoming mails. When a mail arrives, instead of being delivered via procmail directly, is parsed through a script that extracts all attachments from the mail, unpacks (if needed) and scannes them using a professional virus scanner program.

Please note:

This document mainly describes the function and implementation in a Linux environment, but it should be portable to any UN*X available within the limitations outlined in this document ( currently only Linux tested by the authors). Successful installation has also be reported running on SUN Solaris, *BSD, AIX and HP-UX (some with minor modification to the package). Links to software packages point mainly point to source code which should compile under different UN*X systems.

2. System Requirements

2.1 Virus Scanners

Note: For additional information please read README.scanners, too.

2.1.1 Network Associates Virus Scan

Version 3.x Engine
Network Associates''s Virus Scan for AIX, HP-UX, Linux, NCR and Solaris is no longer available from Network Associates. However, you may download the engine using the links above.
An exerpt from NAI's "README" dated 12-15-99 04:22AM:
[..]
                 Release Notes
     for Network Associates 3212 .DAT Files
  Copyright (c) 1992-1999 Networks Associates
     Technology, Inc. All Rights Reserved.

////////////////////////////////////////////////////
/ THIS IS THE FINAL .DAT FILE RELEASE FOR THE V3.X /
/ PRODUCT SERIES. NETWORK ASSOCIATES RECOMMENDS    /
/ THAT YOU UPGRADE TO CURRENT VERSIONS OF YOUR     /
/ ANTI-VIRUS SOFTWARE.                             /
////////////////////////////////////////////////////
[..]
This latest (and last) DAT file is available here
Version 4.x Engine
Cite: "A new Network Associates scanning engine has been created and backed by the combined efforts of the McAfee Labs and Dr Solomon anti-virus research teams to deliver the outstanding virus detection and cleaning rates."

You may try to fetch the current version from a mirror for HPUX, Linux, SCO and Solaris. However, they may not have the lastest Version available.
Direct download from Network Associates is available from the NAI/McAfee Website.
Current DAT files have to be version 4.x and are the same for DOS/Windows. You may also use the daily updated DAT files

Note: This evaluation version is to be used free of charge for a limited time of 30 days. Then it has to be registered.

2.1.2. DrSolomon

DrSolomon's Anti-Virus Toolkit for SCO-UNIX (running with the iBCS kernel module)
Note: DrSolomon has become part of Network Associates (NAI) and their product merged with NAI/McAfee's VirusScan v4

2.1.3 H+BEDV AntiVir/X

AntiVir/X (German + English)
AntiVir/X may be used free of charge in a non commercial environment. Please send a short e-mail with name, address and point out that you want to use AntiVir/X exclusive on your personal system. You then will receive a license for it. Support is avalialable via linux_support@antivir.de

2.1.4 Sophos Sweep

Sophos Anti-Virus for Unix is virus detection and disinfection software which can be installed on Unix file servers and workstations. Binaries for various Unices are available here.

2.1.5 Kaspersky Lab AntiViral Toolkit Pro (AVP)

Kaspersky Lab AntiViral Toolkit Pro (AVP) for Linux is available here.

2.1.6 CyberSoft VFind

CyberSoft VFind is available here

2.1.7 Trend Micro FileScanner

Trend Micro FileScanner is available here. It's free for personal use.

2.1.8 CAI InoculateIT

See CAI's product page and get it here.

2.1.9 F-Secure Inc. (former DataFellows) F-Secure AV

Download it here

2.2 Mail Transport Agents

2.2.1 Sendmail

Sendmail is available at: http://www.sendmail.org/
FIXME: For further information that may not be covered by this document please read the provided file README.sendmail

2.2.2 qmail

qmail is available at: http://www.qmail.org/
FIXME: For now please read the provided file README.qmail

2.2.3 Postfix

Postfix is available at: http://www.postfix.org/
FIXME: For now please read the provided file README.postfix

2.2.4 Exim

Exim is available at: http://www.exim.org/
FIXME: For now please read the provided file README.exim

2.3 MIME Handlers

2.3.1 metamail

most recent version of metamail is available at: ftp://ftp.funet.fi/pub/Linux/PEOPLE/Linus/net-source/mail/tools/. We do not recommend to use it anymore, as it seems not to be maintained and metamail can not handle MIME multipart/alternative messages. Please use reformime out of the maildrop package instead (see below). See also: README.metamail

2.3.2 reformime

reformime is part of the http://www.flounder.net/~mrsam/maildrop/.
Please have a look at README.reformime, too.

2.4 Decompressors

2.4.1 uudecode

Note: GNU uuencode/uudecode 1.0 distribution has been merged into GNU shar utilities 4.2 distribution. Look for sharutils-*.*.tar.gz
available at: ftp://ftp.gnu.org/gnu/sharutils/

2.4.2 compress

From the compress (4.1) manpage:
Compress reduces the size of the named files using adaptive Lempel-Ziv coding. Whenever possible, each file is replaced by one with the extension .Z, while keeping the same ownership modes, access and modification times.

Note: (un)compress is not needed as gunzip is also able to uncompress .Z files.

Source code for compress is available at: ftp://sunsite.unc.edu/pub/Linux/utils/compress/compress.tar.Z

2.4.3 gunzip

From the gzip-1.2.4L.lsm file:
gzip (GNU zip) is a compression utility designed to be a replacement for compress. Its main advantages over compress are much better compression and freedom from patented algorithms.

Source code for gunzip is available at: ftp://sunsite.unc.edu/pub/Linux/compress/gzip-1.2.4L.tar.gz (also available as special Pentium optimized binary version)

2.4.4 unzip

From the unzip-5.31.lsm file:
UnZip 5.31 is a free unarchiver compatible with PKZIP archives (zipfiles) but not a clone of PKUNZIP. This version improves performance somewhat and adds a new "timestamp" function for very fast dating of multiple archives, but most of its new features have to do with better cross-platform support and/or new ports. Multi-part archive support is *not* yet supported (sorry!). Work on that is already underway, however.

Source code is available at: ftp://sunsite.unc.edu/pub/Linux/utils/compress/

A tool named "zipsecure" comes with AMaViS. This program reads a zip file from stdin, removes any pathes of a contained file and changes the name of the file to a new file name. The new name starts with a "z" followed by the process ID and a sequence number. If any extension in the original name was present, it is also appended to the new name.

The provided tool "securetar does similar to tar-files.

2.4.5 unarj

From the unarj241a.lsm file:
Standard unarj un-archiver, provided with the capability of creating directory hierarchies.

Source code is available at: ftp://sunsite.unc.edu/pub/Linux/utils/compress/

2.4.6 unrar

From the unrar-2.04.1.lsm file:
The unRAR utility is a freeware program, distributed with source code and developed for extracting, testing and viewing the contents of archives created with the RAR archiver version 1.50 and above.

Source code is available at: ftp://sunsite.unc.edu/pub/Linux/utils/compress/

2.4.7 xbin

xbin is available as: ftp://sunsite.unc.edu/pub/packages/TeX/tools/xbin/xbinunix.c

2.4.8 LHArc

latest seems to be version 1.14g but there is a version 1.15 at http://shibuya.cool.ne.jp/lha/.

2.4.9 bunzip2

Have a look at the bzip2 homepage at: http://sources.redhat.com/bzip2/

2.4.9 zoo

primary site: ftp://metalab.unc.edu/pub/Linux/utils/compress/

2.4.10 arc

original site: ftp://ftp.uu.net/pub/archiving/
primary site: ftp://metalab.unc.edu/pub/Linux/utils/compress/

2.4.11 freeze

http://metalab.unc.edu/pub/Linux/utils/compress/

2.4.12 tnef

A tool for decoding TNEF files is available at http://world.std.com/~damned/software.html

2.5 File Type Recognition

2.5.1 file

The "file" command is available at ftp://ftp.astron.com/pub/file/ (primary site) or its mirrors ftp://ftp.gw.com/pub/unix/file/ and ftp://ftp.funet.fi/pub/unix/tools/file/.

3. Installation Instructions

3.1 Installing the Software

Installation and operation is described here only for sendmail as SMTP-server. (See also the Future Outlook section of this document)
QMail users please read README.qmail, Postfix users please read README.postfix and Exim users please read README.exim.

3.2 Modifying /etc/sendmail.cf

3.2.1 Modifying /etc/sendmail.cf manually

In your sendmail configuration file (usually /etc/sendmail.cf) the local mail delivery agent needs to be changed (typically this is one of procmail, deliver or mail)
Find the line that begins with Mlocal and change the call for the program which resides after the "P=" directive. This has also to be changed after the "A=" directive:
For example:
Mlocal, P=/usr/bin/procmail, F=lsDFMAw5:/|@SPfhn, S=10/30, R=20/40,
T=DNS/RFC822/X-Unix,
A=procmail -Y -a $h -d $u
changes to:
#Mlocal, P=/usr/bin/procmail, F=lsDFMAw5:/|@SPfhn, S=10/30, R=20/40,
# T=DNS/RFC822/X-Unix,
# A=procmail -Y -a $h -d $u

Mlocal, P=/usr/sbin/scanmails, F=lsDFMAw5:/|@SPfhn, S=10/30, R=20/40,
T=DNS/RFC822/X-Unix,
A=scanmails -Y -a $h -d $u

Please have a look at the FAQ or BUGS if this leads to a malfunction.

Note: If you prefer the m4 technique to configure sendmail, please read below.

3.2.2 Modifying sendmail.cf via M4 macros

Add the following to you .mc file, i.e. linux.mc, just before the MAILER definitions:
dnl change Mlocal to use AMaViS
define(`LOCAL_MAILER_PATH', `/usr/sbin/scanmails')dnl
define(`LOCAL_MAILER_ARGS', `scanmails -Y -a $h -d $u')dnl
Note: On some systems, i.e. SuSE Linux, procmail is not suid for security reasons (see BUGS). So, if you're using sendmail 8.10.x or above, you may add
dnl for security reasons on some systems procmail is not suid.
dnl so we have to add the "o" flag and remove the "S"-flag
dnl see BUGS for details on this issue
MODIFY_MAILER_FLAGS(`LOCAL', `+o')dnl
MODIFY_MAILER_FLAGS(`LOCAL', `-S')dnl

3.3 Test Installation

So, how do you test if your installation has been successful? Don't ask me to send a wild virus ;-). Instead, create a file called eicar.com with the following contents:

X5O!P%@AP[4\PZX54(P^)7CC)7}$EICAR-STANDARD-ANTIVIRUS-TEST-FILE!$H+H*

(The file should end up being 69 bytes long). As an alternative, feel free to download the file at: http://www.eicar.org/download/eicar.com
This should be recognized as a test pattern. It is NOT a virus, just a test pattern that triggers the alert. Use this file in your mail. Try sending it as binhex, tar'ed, gzip'ed, uuencoded, etc.
For more information visit the Eicar Anti-Virus test file webpage

4. Download

Current versions are available at http://www.amavis.org/download/

5. Future Outlook

Features to be added to next Version:

6. Bugs

Send bugreports to: amavis@aachalon.de or to our amavis-bugs mailing list. Prior to this, please read through the files FAQ or BUGS provided and check through the mailing list archive to be sure your bug has not already been discovered.
Please include information about the system you are using (eg. Linux, Solaris,...), the OS or distribution release (eg. RedHat 5.2, SuSE 6.0, SUN Solaris 2.6, ...) and anything that might be useful to trace a bug or shortcoming (like exerpts from your logfile which ususally is /var/log/scanmails/logfile and/or /var/log/maillog)...

7. Disclaimer

The software is provided as is. Please bear in mind that we have done this in our spare time. While it is as accurate as we could make it there is a reasonable chance that there are mistakes somewhere in here. If you email us and tell us about them we will be happy to fix them but we can't take responsibility for your system. Basically use this at your own risk.

7. Copyright

AMaViS - A Mail Virus Scanner (c) 1997..2000 Mogens Kjaer, Carlsberg Laboratory mk@crc.dk, Jürgen Quade quade@amavis.org, Christian Bricart, shiva@aachalon.de, Rainer Link link@suse.de, Lars Hecking lhecking@nmrc.ie and others.

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation; either version 1, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

Product names and various content (including but not limited to audio, video, and graphics) are trademarks of their respective owner.

8. Credits

  • initial code
 Mogens Kjaer
  • minor modifications
  • press work
 Jürgen Quade
  • minor modifications and enhancements
  • official Website
  • official support e-mail adress
  • packet mainenance
 Christian Bricart
  • bug fixes and code improvements
  • qmail support
Chris L. Mason
  • modifications and enhancements
  • added support for several anti-virus products
  • added support for exim and postfix (based on work from Lars Hecking)
  • product support
  • thanks to SuSE Germany for funding my work
Rainer Link

9. AMaViS in the Press

10. History and Changes

for a full description of changes have a look at the ChangeLog
$Revision: 1.7 $ $Date: 2000/10/31 10:59:53 $ amavis@aachalon.de
